Hot Smoke
The Crompton Hot Smoke range was developed for buildings where the control and containment of hot smoke is critical to life safety. Designed for protected escape routes, plant areas and compartmentation zones, it combines fire performance, smoke control and thermal efficiency within a robust steel doorset platform.
Developed for environments where smoke control is as important as fire resistance, Crompton Hot Smoke helps support evacuation strategies and building safety requirements. Suitable for commercial buildings, public sector facilities and infrastructure environments, it provides reliable protection while supporting the movement of people during emergency situations.
-
Fire Rated Up to E120
-
31dB
-
1.6 - 2.2 W/m²K
-
Sa & S200
Construction & Materials
45mm thick steel leaf manufactured from 1.5mm Zintec skins with stainless steel cross sections and internal reinforcement.
100mm deep fixed frame manufactured from Zintec and stainless steel for secure installation into suitable supporting structures.
Reinforced steel construction developed for external commercial and industrial environments.
Teardrop and intumescent seal arrangement with 12mm step threshold. Available in polyester powder coated, wet paint and polished stainless steel finishes.
Performance Ratings
Performance values shown relate to the single door configuration only. Alternative configurations may vary depending on specification and project requirements.
| Variant | Fire | Acoustic | Security | U-Value | Wind | Smoke |
|---|---|---|---|---|---|---|
| Hot Smoke | E120 | 31dB | - | 1.6 - 2.2 | Sa & S200 | Pending |
