The FPF range is a specialist fire doorset developed for infrastructure applications requiring pressure resistance, acoustic insulation and controlled access performance. Combining reinforced steel construction with specialist sealing systems and thermal barrier technology, FPF is designed for secure operation in demanding environments.
Manufactured using reinforced steel construction with insulated core technology and specialist sealing arrangements, FPF is designed for environments where fire performance, acoustic control and structural resilience are essential. Multi point locking systems and passive leaf configurations support dependable long term operation across infrastructure and secure operational environments.
-
Fire rated up to E180
-
37dB
-
Sa4 & S200
Construction & Materials
110mm thick leaf construction with internal steel channel framing incorporating Searox Rockwool and Marineflex insulation. Passive side leaf formed with RHS internal construction and Searox Rockwool insulation.
Approximate leaf mass of 143kg.
4mm 316L stainless-steel frame construction with 5mm 316L stainless-steel threshold. Frame profile incorporates a thermal barrier between the two frames.
Reinforced steel construction with insulated core technology developed for pressure-resistant environments.
Specialist sealing arrangement includes Tadpole seals, Pyroplex intumescent strips, Lorient centre seals and SCHALL-EX drop seals fitted to both leaves.
Performance Ratings
Performance values shown are based on the single door configuration only and may vary depending on specification and hardware selection.
| Variant | Fire | Acoustic | Security | U-Value | Smoke | Wind |
|---|---|---|---|---|---|---|
| FPF | E180 | 37dB | - | - | Sa4 & S200 | - |
Swipe to see more
