Belmont
The Belmont doorset is designed for high security and critical infrastructure applications where fire resistance, attack resistance and durability are essential. Combining reinforced steel construction with acoustic and smoke performance, Belmont provides a robust solution for projects requiring enhanced protection without compromising operational functionality.
Built around a reinforced internal cassette construction with bonded attack barrier technology, Belmont is developed to withstand demanding operational conditions. Heavy duty welded steel components, security rated locking systems and reinforced frame construction support long term performance across transport, infrastructure and secure facilities.
-
Fire Rated up to E120
-
Up to 38dB
-
LPS1175-C5
-
Pending
-
Sa
-
Pending
Construction & Materials
61mm thick steel leaf incorporating an internal cassette with bonded attack barrier reinforcement. Approximate leaf weight of 300kg per leaf.
120mm x 65mm single rebate “P” profile frame in reinforced steel construction with welded joints, reinforced gussets and 5mm hinge/fixing plates.
Fully welded heavy duty steel construction designed for concrete and brickwork applications.
3mm stainless steel threshold with optional integral sealing. Available in zinc coated steel or stainless steel finishes with PPC or wet paint coating options.
Performance Ratings
Tested performance values vary depending on configuration, hardware selection and project specific requirements.
| Variant | Fire | Acoustic | Security | U-Value | Smoke | Wind |
|---|---|---|---|---|---|---|
| Belmont | E120 | 38dB | LPS1175-C5 | - | Sa | - |
Swipe to see more
